Self-Loading Positioning Wheel Dollies

The dollies incorporate roller tables that support the tire while allowing it to rotate smoothly in place. On the Hydraulic Wheel Dolly, two roller tables with three rollers each facilitate wheel rotation and alignment. This functionality allows operators to align wheel bolt holes and hub studs without needing to lift or manually wrestle heavy equipment tires.

Power mechanisms vary across models to match shop and field requirements. The Hydraulic Wheel Dolly uses a two-stage hydraulic pump for smooth manual lifting action. In contrast, the Heavy Duty Ag Wheel Dolly utilizes a 12V over hydraulic system featuring a handheld control for adjusting roller width, delivering motorized convenience during tire service operations.

The BS3800 Hydraulic Wheel Dolly accommodates tires ranging from semi tires up to 800 metric sizes. Specifically, it supports tires with a minimum wheel diameter of 39 inches, a maximum wheel diameter of 86 inches, and a maximum wheel width of 31 inches. This versatility makes it suitable for diverse agricultural and industrial machinery.

Yes, the BS3800 Hydraulic Wheel Dolly is engineered to work directly with the Bierman Tire Safety Rack. Operators can maneuver and transfer tires to the safety rack without first removing the tire from the dolly, streamlining tire handling, service, and storage workflows in busy agricultural equipment dealerships and maintenance shops.

Both models incorporate dedicated retention mechanisms to secure heavy tires during handling. The BS3800 includes an adjustable retaining arm and two support handles for enhanced control. The Heavy Duty Ag Wheel Dolly features a safety arm with three placement positions, ensuring large agricultural and truck wheels remain firmly upright and stable during service.

Pricing for our wheel dollies is available upon request. Equipment is not sold directly online and must be ordered by contacting our team by phone or email. Technicians and equipment dealers can connect with our Marcus, Iowa headquarters at 712.324.1930 or email sbierman@biermansales.com to receive model availability and detailed purchasing information.
